System configurator and order-information guide
I
PRIMERGY TX150 S4 Status 25.11.2005
Section
IX
Communication / Network
Gigabit Ethernet Contr. on-board The Intel LAN controllers 1000MT can be used
Broadcom with the on-board controller in Teaming Mode
ext: for RJ 45-connector
SW: AFT, VLAN, Fast Channel
S26361-F3053-E1 S26361-F3142-E1
Gigabit Ethernet Contr. 1000TX Gigabit Ethernet Contr. 1000TX
Eth. Ctrl 1x1Gbit PCI-X Pro/1000MT Cu Eth. Ctrl 1x1Gbit PCI32 PRO/1000GT Cu
Intel PRO/1000 MT Server Adapter Intel Pro/1000 GT Adapter
Adapter Teaming Support
PCI 32 (33/66MHz),
PCI-X (PCI64/133), min 165 mm ext: for RJ45-plug, Cat 5
ext: for RJ45-plug, Cat 5
connection with Cat 5 cabling
connection with Cat 5 cabling SW: VLAN, Fast & Gbit Etherchannel
SW: VLAN, Fast & Gbit Etherchannel
max. 4x per system
max. 4x per system
4x
S26361-F3011-E1
Gigabit Ethernet Contr dual 1000TX
Intel Pro/1000MT dual Server Adapter
Adapter Teaming Support
PCI-X (PCI64/133), min 163 mm
ext: for RJ45-plug, Cat 5
connection with Cat 5 cabling
SW: VLAN, Fast Etherchannel
max. 2x per system
S26361-F1809-E2
ISDN S
O
Controller PCI
Eicon Diva Server BRI-2M 2.0
Incl. S
O
-connector
occu. short PCI slot min. 170 mm
SO-Interface
max. 2x per system
J
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server
15 of 18
