Fujitsu PRIMERGY TX150 S8 Datasheet

Data Sheet FUJITSU Server PRIMERGY TX150 S8 Mono-Socket Intel® Xeon® processor server
Page 3 / 10 www.fujitsu.com/fts
Technical details
PRIMERGY TX150 S8
Base unit PRIMERGY TX150 S8 LFF PRIMERGY TX150 S8 LFF PRIMERGY TX150 S8 SFF PRIMERGY TX150 S8 SFF
Housing types Tower Tower Tower Tower
Storage drive architecture 3.5-inch 3.5-inch 2.5-inch 2.5-inch
Power supply Standard Hot-plug Standard Hot-plug
Mainboard
Mainboard type D 3079
Chipset Intel® C602
Processor quantity and type 1 x Intel® Pentium® processor / Intel® Xeon® processor E5-1400 product family / Intel® Xeon® processor E5-2400 product
family
Processor Intel® Pentium® processor 1403
(2C/2T, 2.60 GHz, TLC: 5 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,066 MHz, 80 W)
Intel® Xeon® processor E5-1410
(4C/8T, 2.80 GHz, TLC: 10 MB, Turbo: Yes, 6.4 GT/s, Mem bus: 1,333 MHz, 80 W)
Intel® Xeon® processor E5-2403
(4C/4T, 1.80 GHz, TLC: 10 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,066 MHz, 80 W)
Intel® Xeon® processor E5-2407
(4C/4T, 2.20 GHz, TLC: 10 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,066 MHz, 80 W)
Intel® Xeon® processor E5-2420
(6C/12T, 1.90 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2430
(6C/12T, 2.20 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2430L
(6C/12T, 2.00 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 60 W)
Intel® Xeon® processor E5-2440
(6C/12T, 2.40 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2450
(8C/16T, 2.10 GHz, TLC: 20 MB, Turbo: Yes, 8.0 GT/s, Mem bus: 1,600 MHz, 95 W)
Memory slots 6 (6 DIMMs, 3 channels with 2 slots per channel)
Memory slot type DIMM (DDR3)
Memory capacity (min. - max.) 2 GB - 96 GB
Memory protection Advanced ECC
Memory Scrubbing
SDDC (Chipkill™)
Hot-spare memory support
Memory Mirroring support
Memory notes max. 96 GB registered; min. 2 GB unbuffered; Memory Mirroring with identical modules in both channel pairs of a bank
(2 modules per bank). Rank sparing with identical modules within the same channel. Performance Mode with identical
modules in all channels of each bank per CPU.
Memory options 4 GB (1 module(s) 4 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, single rank
8 GB (1 module(s) 8 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
16 GB (1 module(s) 16 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
Memory options 4 GB (1 module(s) 4 GB) DDR3 LV, unbuffered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
Interfaces
USB 2.0 ports 9 x USB 2.0 (2x front, 4x rear, 3x internal for backup, UFM and internal USB)
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC or system or shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S3 (10/100/1000 Mbit/s)
Management LAN trafc can be switched to shared onboard Gbit LAN port
