22
Modular RAID Controllers
Modular RAID 3Gb/s (SAS1.0)
●
Optionally secured with BBU
●
Offers advanced MegaRAID functionality to integrated LSI SAS
●
3.3 V PCIe add-in card
●
4-lane 2.5 Gbit PCIe host bus
●
8 SAS/SATA ports
●
Each SAS/SATA port supports SSP, SMP and STP
●
Support for the following STP features:
– Addressing of SATA targets through expander
– Native Command Queuing (NCQ)
●
Support of the following SSP features:
– Wide port functionality (2 or 4 Phys from a single quad port)
– Narrow port functionality (1 Phy)
– Compatible with SATA target devices
●
2 Mini 4x SFF-8087 connectors
●
Hot-plug drives
●
SGPIO interfaces for signaling of SAS/SATA ports
●
Hardware XOR for RAID parity calculations
●
72-bit wide 256 / 512 MB of DDR2 667 (with ECC)
3.2.2 Controller versions
Name Chip Cache No. of SAS
channels
Bracket
type
S26361-D2516-A1x/Cx LSISAS1078e 256 MB 8 without
low profile
full height
S26361-D2516-B1x/Dx LSISAS1078e 512 MB 8 without
low profile
full height
