Modular RAID Controllers 39
Modular RAID 6Gb/s (SAS2.0)
4.2.2 Controller versions
4.2.3 Connectors and indicators
The following figure shows the location of the connectors and indicators on the
SAS RAID controller.
Name Chip Cache
No. of SAS
channels
Bracket
type
S26361-D2616-Ax LSI SAS2108 512 MB 8
low profile
full height
1 iBBU connector 3 SAS cable connectors
2 LEDs 4 HDD LED connector
1
2
3
4

Fujitsu RAID Ctrl SAS 6G 5/6 512MB Specifications

General

Brand	Fujitsu
Model	RAID Ctrl SAS 6G 5/6 512MB
Category	Controller
Language	English
