Modular RAID Controllers
71
Modular RAID 6Gb/s (SAS2.0)
4.6.1 Features
●
Flexibility for both SAS 2.0 and SATA II / SATA III
●
Advanced management and configuration suites
●
12V PCIe RAID HDD module
●
Supports RAID levels 0, 1, 1E, 10
●
Offers advanced MegaRAID functionality to integrated LSI SAS
●
8-lane 5.0 / 8.0 Gbit PCIe host bus
●
6 SAS/SATA ports, (2+2 ports for Storage Blade Connection and 2 ports for
Blade internal HDD Connection)
●
Each SAS/SATA port supports SSP and STP
●
Support for the following STP features:
– Addressing of SATA targets through expander
– Native Command Queuing (NCQ)
●
Support of the following SSP features:
– Wide port functionality (2x2 Phys from a single quad port)
– Narrow port functionality (1 Phy)
– Compatible with SATA target devices
●
SGPIO interfaces for signaling of SAS/SATA ports
●
Drive spin-up sequencing control
●
Hot-plug drives
●
1.5 Gbit/s, 3.0 Gbit/s and 6.0 Gbit/s link rates for both SAS an SATA
4.6.2 Controller versions
Name Chip PCIe No. of SAS channels
S26361-D2837-Ax LSI SAS2208 PCIe 2.0
2 ports for Blade internal
HDD Connection
S26361-D2837-Cx LSI SAS2208 PCIe 3.0
2 ports for Blade internal
HDD Connection
