FULTON FT-0160C - Setting the Complete Range

FT-C Vertical Electric Thermal Fluid Heater Manual 12 2013 ISSUE 1




1) Remember it is only necessary to approximate the setting through the modulation range until
high re conditions are established.
2) Press Enter once more to have access to the point number eld. Increase the point number
by one and press Enter. Select ChangePoint and press Enter. The servos will now move to that
point.
3) Verify combustion is satisfactory.
4) Measure input or monitor last elbow pressure. Verify that these points are in general
correspondence with the test re sheet. Repeat step 2 until the point position has a load value
of 100%.
5) You are now at high re. Verify combustion is per test re sheet.
6) Once at high re, adjust the incoming gas pressure at the main gas regulator to match the test
re report. Adjust the gas servo motor to change the last elbow pressure to match the test re
report.
7) Adjust the air servo motor to adjust the emissions as needed.
8) Repeat step 2 but start at the high re point number. Continually decrease the point number
after combustion has been veried at each point.
9) Once all the points have been veried, press Escape until you are back to the main menu.
10) You can observe the status of the burner by going to OperationalStat>NormalOperation.
11) Turn the main ON/OFF switch to OFF. The control will now postpurge. Verify ignition using steps
from Setting Main Burner Ignition with the new gas pressures.
12) Turn the main burner switch to OFF. The control will now post purge.
13) Under Manual Operation > Auto/Manual/OFF , change the operation to Automatic and press
Enter and conrm Automatic is entered in the current eld.
14) Press Escape twice to get back to the main menu.
15) Under Updating >ParamBackup, select LMV51 – AZL. This will store all of the adjustments that
have been made in the LMV base module to the display. If the base module fails in the future,
the display can be used to download all of the parameters into a new base module.
16) The heater is now ready to run. Adjust your setpoint on the temperature control to the desired
temperature and turn the main ON/OFF switch to ON for the burner to operate.
