FT-C Vertical Electric Thermal Fluid Heater Manual 12 2013 ISSUE 1
The following specications, data, equipment and operating descriptions apply to typical Fulton
thermal units. These sections are provided for general information purposes only, and do not
necessarily reect the specic details of individual systems.
At commissioning, the operation of all safeties and interlocks should be veried.
Setpoints of all pressure and temperature switches as well as the programs for all
programmable controls (temperature controls, temperature limits, operating controls, servo
motors etc.) should be recorded for future reference. Contact the Fulton Service Department
with any questions regarding the proper operation, set points and verication procedures for
these controls.
Alarm Buzzers
Power On Indicator
Flame Sensor Light and
Reset Button
Oil Valve Open
Indicator
Deaerator Low
Level Indicator
Fan On Indicator
Thermal Fluid Pressure
Alarm and Reset Button
High Limit Temperature
Fuel Pressure Alarm
Indicator
Door Isolator
Heater On/
Off Switch
Ignition Indicator
Operating Temperature
Controllers
Pump Run Indicator
Pump On/Off Switch
