FUNAI 29B-250 - Page 54

20040715 1-15-9 HG242EL
SUB JACK CBA
JACK CBA
REMOTE RECEIVER PIC-37042LQ USESJRSKK038
T001! SWITCHING TRANSFORMER 04749 or LTT00EPKT160
! PULSE TRANS. BCK-25-060D LTT00EPXB016
TP301 PCB JUMPER D0.6-P10.0 JW10.0T
TP501 PCB JUMPER D0.6-P6.0 JW6.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP506 PCB JUMPER D0.6-P5.0 JW5.0T
TP507 PCB JUMPER D0.6-P6.0 JW6.0T
TU701 A TUNER UNIT TMDG1-662A UTUNPLJAL015
TU701 B TUNER UNIT TMDG2-662A UTUNPLJAL016
VR501 CARBON P.O.T. 100k Ω B VRCB104HH014
X301 X'TAL 4.433619MHz or FXC445LLN001
X'TAL 4.433619MHz 1811388
X501 X'TAL 12.000MHz FXD126LDS001
X502 X'TAL 32.768kHz(20PPM) or FXC323LQUA01
X'TAL 32.768kHz(20PPM) FXC323LDS002
Ref. No. Mark Description Part No.
B SUB JACK CBA (MCV-B)
Consists of the following:
-----------
CAPACITORS
C751 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C752 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
RESISTORS
R751 B CHIP RES.(1608) 1/10W J 820 Ω RRXAJR5Z0821
R752 B CHIP RES.(1608) 1/10W J 820 Ω RRXAJR5Z0821
MISCELLANEOUS
JK751 B RCA JACK MSP-282V-12 PBSN JXRL030LY011
JW003 B FLAT CABLE, 3P AWG26#2651/P2.0/200 WX1HE480-001
Ref. No. Mark Description Part No.
JACK CBA (MCV-C)
Consists of the following:
-----------
CAPACITORS
C101 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C102 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C103 B CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
B CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C104 CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C107 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C108 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C109 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C110 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C111 B CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
B CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C112 CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C115 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C116 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C117 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
Ref. No. Mark Description Part No.
DIODES
D101 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D102 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D103 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D105 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COILS
L101 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L102 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
TRANSISTORS
Q101 TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q102 TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
RESISTORS
R101 A CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R101 B CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R102 A CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R103 B CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R104 B CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
B CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R105 A CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
A CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R106 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R108 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R109 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R110 A CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R110 B CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R111 A CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R112 B CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R113 B CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
B CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R114 A CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
A CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R115 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R116 CARBON RES. 1/6W J 15k Ω or RCX6JATZ0153
CARBON RES. 1/4W J 15k Ω RCX4JATZ0153
R117 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R118 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R119 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R120 CARBON RES. 1/6W J 680 Ω or RCX6JATZ0681
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R123 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R125 CARBON RES. 1/6W J 680 Ω or RCX6JATZ0681
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R126 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R127 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
2L022 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
A5 JACK BOARD(2-21P) HE470ED 0VM203835
JK101 RGB CONNECTOR MRC-021V-01 JXGL210LY002
JK102 RGB CONNECTOR MRC-021V-01 JXGL210LY002
Ref. No. Mark Description Part No.
