20040715 1-15-10 HG242EL
SENSOR CBA
AFV CBA
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
0VSA14893
TRANSISTORS
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q505 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
BAFV CBA
Consists of the following:
0VSA14914
CAPACITORS
C1 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C4 B CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
B CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C5 B CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
B CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C6 B CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
B CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C7 B CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
B CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
B CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 B CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
B CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
B CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 B CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C12 B ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C13 B CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 B CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 B ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C16 B ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C17 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C19 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C20 B ELECTROLYTIC CAP. 3.3µF/50V M H7 CE1JMASSL3R3
C21 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C22 B ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 B ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
CONNECTOR
CN1 B ANGLE PIN HEADER, 9P 6029B-1-09Z003-T 5700069
DIODES
D2 B SWITCHING DIODE 1N4148M or NDTZ01N4148M
B SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC1 B IC:AUDIO PROCESSOR MSP3417G-QG-B8
or
NSZBA0SP3002
B IC:AUDIO PROCESSOR MSP3417G-QG-B8-
V3
NSZBA0SP3005
COILS
L1 B INDUCTOR 10µH-K-26T LLAXKATTU100
L2 B PCB JUMPER D0.6-P5.0 JW5.0T
L3 B INDUCTOR 18µH-K-26T LLAXKATTU180
L4 B INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 B CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R4 B CHIP RES.(1608) 1/10W J 120k Ω RRXAJR5Z0124
R5 B CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
X1 B X'TAL 18.432MHz FXD186LLN001
Ref. No. Mark Description Part No.
To Next Page
