FUNAI DR-C3835 - Page 54

20060331 1-17-3 E7B22EL
C1290 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1291 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C1294 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C1295 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1296 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1297 ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTM470
C1301 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1302 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1303 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTM101
C1501 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C1502 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C1504 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
If C1507 is 0.015µF, then IC1502 is R3112N191A-TR-FA, R3112N191A-TR-FB or
BU4219G-TR.
C1507 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
IC1502 VOLTAGE DETECT R3112N191A-TR-FA
or
QSZBA0TRC021
VOLTAGE DETECT R3112N191A-TR-FB
or
QSZBA0TRC022
RESET IC BU4219G-TR QSZBA0TRM090
If C1507 is 0.1µF, then IC1502 is PST3619NR.
C1507 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
C1508 CERAMIC CAP.(AX) F Z 0.1µF/ 50V CCA1JZTFZ104
C1509 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C1510 CERAMIC CAP.(AX) F Z 0.1µF/ 50V CCA1JZTFZ104
C1512 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1515 ELECTROLYTIC CAP. 22µF/ 50V M or CE1JMASDL220
ELECTROLYTIC CAP 22µF/ 50V M CE1JMASTM220
C1517 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1519 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1520 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1521 ELECTROLYTIC CAP. 3.3µF/ 50V M or CE1JMASDL3R3
ALUMINUM ELECTROLYTIC CAP 3.3µF/
50V M
CE1JMASTM3R3
C1522 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1523 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1524 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTM101
C1526 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1527 ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTM470
Ref. No. Mark Description Part No.
C1641 B CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C1645 B CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1646 B ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
B ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V M
CE1EMASTM4R7
C1647 B SEMICONDUCTOR CAP. SR K 0.018µF/
25V
CDA1EKS0X183
C1648 B ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
B ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1649 B ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
B ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1650 B CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1651 B ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
B ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTM470
C1704 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1708 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1709 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1710 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1711 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1713 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1714 ELECTROLYTIC CAP. 10µF/ 50V M or CE1JMASDL100
ALUMINUM ELECTROLYTIC CAP 10µF/
50V M
CE1JMASTM100
C1715 ELECTROLYTIC CAP. 0.33µF/ 50V M or CE1JMASDLR33
ALUMINUM ELECTROLYTIC CAP
0.33µF/ 50V M
CE1JMASTMR33
C1716 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1801 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1803 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1806 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1807 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1808 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1809 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1811 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1812 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1813 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1814 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1816 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1817 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1819 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1820 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1821 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1823 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1825 ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTM470
C1827 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1831 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C1833 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1834 ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTM470
Ref. No. Mark Description Part No.
