20060331 1-17-4 E7B22EL
CONNECTORS
CN1152 242 SERIES CONNECTOR
224202115W1
J322C15TG001
CN1601 PH CONNECTOR (WHITE) TOP 2P B2B-
PH-K-S(LF)
J3PHC02JG017
CN1701 A AFV PCB ASSEMBLY E6852FD E6852AFV
CN1701 B AFV PCB ASSEMBLY E6851BD E6851AFV
DIODES
D1151 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1154 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1156 ZENER DIODE DZ-10BSBT265 or NDTB00DZ10BS
ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D1157 PCB JUMPER D0.6-P5.0 JW5.0T
D1158 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1159 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1160 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1162 ZENER DIODE DZ-11BSBT265 or NDTB00DZ11BS
ZENER DIODE MTZJT-7711B QDTB00MTZJ11
D1163 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS
ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1165 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1166 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1167 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1170 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1171 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1172 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1173 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1174 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1175 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1501 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1502 ZENER DIODE DZ-7.5BSAT265 or NDTA0DZ7R5BS
ZENER DIODE MTZJT-777.5A QDTA0MTZJ7R5
D1507 ZENER DIODE DZ-4.3BSCT265 or NDTC0DZ4R3BS
ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3
D1508 ZENER DIODE DZ-5.6BSCT265 or NDTC0DZ5R6BS
ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D1509 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1601 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1701 ZENER DIODE DZ-33BSBT265 or NDTB00DZ33BS
ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D1801 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1802 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1803 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1804 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1805 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1806 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
Ref. No. Mark Description Part No.
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1807 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1808 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1809 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1810 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1811 ZENER DIODE DZ-4.3BSCT265 or NDTC0DZ4R3BS
ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3
ICS
IC1151 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1152 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1153 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC1201 IC INTERFACE HA118326ApF-E QSZBA0RHT051
IC1202 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP RC4580IP NSZBA0STY173
IC1203 IC OP AMP RC4580IP NSZBA0STY173
IC1501 MICROCONTROLLER 8BIT MN101C77A
FM
QSZAA0RMS051
If IC1502 is R3112N191A-TR-FA, R3112N191A-TR-FB or BU4219G-TR, then
C1507 is 0.015µF.
IC1502 VOLTAGE DETECT R3112N191A-TR-FA
or
QSZBA0TRC021
VOLTAGE DETECT R3112N191A-TR-FB
or
QSZBA0TRC022
RESET IC BU4219G-TR QSZBA0TRM090
C1507 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
If IC1502 is PST3619NR, then C1507 is 0.1µF.
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
C1507 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
IC1503 VFD DRIVER IC SC16313G or NSZBA0T0S005
VFD DRIVER/CONTROLLER IC PT6313-
S-TP(L)
NSZBA0TG2007
IC1641 B IC VPS/PDC SLICER LC74793JM-TLM-E QSZBA0TSY018
COILS
L1201 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1203 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1205 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1206 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1207 PCB JUMPER D0.6-P5.0 JW5.0T
L1209 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1502 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1703 INDUCTOR 10µH-K-26T LLAXKATTU100
L1801 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1802 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1803 BEAD CORE ASSEMBLY E6820ED 1VSA11351
TRANSISTORS
Q1154 TRANSISTOR KTC3266-GR-AT/P or NQS4KTC3266P
TRANSISTOR KTC3266-Y-AT/P or NQSYKTC3266P
TRANSISTOR 2SC3266-GR(TPE2 F) or QQS12SC3266F
TRANSISTOR 2SC3266-Y(TPE2 F) QQSY2SC3266F
Q1155 TRANSISTOR KTA1273-Y-AT/P or NQSYKTA1273P
TRANSISTOR 2SA966-Y(TE6 F M) QQSY02SA966F
Q1156 TRANSISTOR 2SC2001-T-A-K or QQSK2SC2001A
TRANSISTOR 2SC2001-T-A-L QQSL2SC2001A
Q1157 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1158 TRANSISTOR KTC3203-Y-AT/P or NQSYKTC3203P
Ref. No. Mark Description Part No.
