20060331 1-17-8 E7B22EL
PSV CBA
POWER SUPPLY CBA
TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW3008 TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW3009 TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW3010 TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
Ref. No. Mark Description Part No.
A
B
PSV CBA
PSV CBA
Consists of the following:
1VSA13852
1VSA14347
POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
JACK CBA (PSV-C)
----------
----------
----------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
----------
CAPACITORS
C1001! METALIZED FILM CAP. 0.068µF/ 250V K
or
CT2E683DC011
! METALIZED FILM CAP. 0.068µF/ 250V K
or
CT2E683DC014
! METALIZED FILM CAP. 0.068µF/ 250V M CT2E683MS037
C1002! ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
! ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1003 CERAMIC CAP. YV Z 0.022µF/ 50V CCD1JZSYV223
C1004! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C1005 ELECTROLYTIC CAP. 100µF/ 400V M CA2H101S6016
C1006 CERAMIC CAP.(AX) X K 1800pF/16V CCA1CKT0X182
C1008 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C1009 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C1010 CERAMIC CAP. B K 0.01µF/ 500V CCD2JKP0B103
C1101 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471
C1104 CHIP CERAMIC CAP.(1608) B K 0.033µF/
50V
CHD1JK30B333
C1106 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTM101
C1107 ELECTROLYTIC CAP. 22µF/ 50V M or CE1JMASDL220
ELECTROLYTIC CAP 22µF/ 50V M CE1JMASTM220
C1108 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1109 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1110 ELECTROLYTIC CAP. 1000µF/ 6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/ 6.3V M CE0KMASTM102
C1111 ELECTROLYTIC CAP. 3300µF/ 6.3V SL or CE0KMZADL332
ELECTROLYTIC CAP. 3300µF/ 6.3V SM
or
CE0KMZPDL332
ALUMINUM ELECTROLYTIC CAP
3300µF/ 6.3V M
CE0KMZPTM332
C1112 ELECTROLYTIC CAP. 1000µF/ 16V M or CE1CMASDL102
ALUMINUM ELECTROLYTIC CAP
1000µF/ 16V M
CE1CMZPTM102
C1113 ELECTROLYTIC CAP. 10µF/ 50V M or CE1JMASDL100
ALUMINUM ELECTROLYTIC CAP 10µF/
50V M
CE1JMASTM100
C1114 ELECTROLYTIC CAP. 4700µF/ 6.3V SL or CE0KMZADL472
ELECTROLYTIC CAP. 4700µF/ 6.3V SM
or
CE0KMZPDL472
Ref. No. Mark Description Part No.
ALUMINUM ELECTROLYTIC CAP
4700µF/ 6.3V M
CE0KMZPTM472
C1115 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1116 ELECTROLYTIC CAP. 1000µF/ 6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/ 6.3V M CE0KMASTM102
C1117 ELECTROLYTIC CAP. 470µF/ 16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/ 16V M CE1CMASTM471
C1120 ELECTROLYTIC CAP. 1000µF/ 6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/ 6.3V M CE0KMASTM102
DIODES
D1001 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1002 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1003 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1004 DIODE 1N5397-B or NDLZ001N5397
DIODE 1N5397BD NDL1001N5397
D1005 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1007 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1009 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1010 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1011 RECTIFIER DIODE BA159 or NDQZ000BA159
RECTIFIER DIODE BA159 NDWZ000BA159
D1013 PCB JUMPER D0.6-P5.0 JW5.0T
D1101 RECTIFIER DIODE BA157 or NDQZ000BA157
RECTIFIER DIODE BA157 NDWZ000BA157
D1102 SCHOTTKY BARRIER DIODE SB380 NDQZ000SB380
D1103 RECTIFIER DIODE BA157 or NDQZ000BA157
RECTIFIER DIODE BA157 NDWZ000BA157
D1104 RECTIFIER DIODE BA157 or NDQZ000BA157
RECTIFIER DIODE BA157 NDWZ000BA157
D1105 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1107 SCHOTTKY BARRIER DIODE SB240-B/
P or
NDQZ000SB240
SCHOTTKY BARRIER DIODE SB240-B/
P
NDWZ000SB240
D1108 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D1111 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D1112 ZENER DIODE DZ-20BSAT265 or NDTA00DZ20BS
ZENER DIODE MTZJT-7720A QDTA00MTZJ20
D1113 ZENER DIODE DZ-15BSBT265 or NDTB00DZ15BS
ZENER DIODE MTZJT-7715B QDTB00MTZJ15
ICS
IC1001
!
PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
COILS
L1001! BEAD CORE ASSEMBLY E6820ED 1VSA11355
L1002 BEAD CORE ASSEMBLY E6820ED 1VSA11355
L1003 BEAD CORE ASSEMBLY E6820ED 1VSA11355
L1004! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503(PB
FREE)
LLBG00ZKQ014
Ref. No. Mark Description Part No.
To Next Page
