20060331 1-17-9 E7B22EL
JUNCTION CBA
JACK CBA
L1005 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1101 POWER INDUCTORS TWKBNP-150K or LLC150KKV007
CHOKE COIL(15µH) LHL10NB150K or LLARKGQTU150
POWER INDUCTORS CWKBNP-150K LLF1500KV002
L1102 POWER INDUCTORS TWKBNP-180K or LLC180KKV007
CHOKE COIL(18µH) LHL10NB180K or LLARKGQTU180
POWER INDUCTORS CWKBNP-180K LLF1800KV002
L1105 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
TRANSISTORS
Q1001 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1002 TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1003! FET 2SK3566 QFWZ02SK3566
Q1101 TRANSISTOR KTA1267-Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
RESISTORS
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1005 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1006 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1007 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1009 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1010 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1011 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1012 CARBON RES. 1/6W J 1.5k Ω or RCX6JATZ0152
CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1013 CARBON RES. 1/4W G 820 Ω RCX4GATZ0821
R1014 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1016 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN01JZLZ02R7
METAL OXIDE FILM RES. 1W J 2.7 Ω RN01JZQZ02R7
R1017 CARBON RES. 1/6W J 5.6k Ω or RCX6JATZ0562
CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R1018 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1019 METAL OXIDE FILM RES. 2W J 82k Ω or RN02823ZU001
METAL OXIDE FILM RES. 2W J 82k Ω RN02823KE010
R1020 METAL OXIDE FILM RES. 1W J 1.8 Ω or RN011R8ZU001
METAL OXIDE FILM RES. 1W J 1.8 Ω RN011R8KE010
R1101 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1102 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1103 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1104 CHIP RES. 1/10W J 1.8k Ω RRXAJR5Z0182
R1105 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1106 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES. 1/10W F 2.2k Ω RRXAFR5Z0222
R1108 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1109 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
MISCELLANEOUS
2B11 HEAT SINK E6800ED 1VM420987
2L019 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
AC1001
!
A AC CORD PE8G2CG9G0AB05 WAE0172LW011
AC1001
!
B AC CORD PE8G2X91H0AA061 WAB0182LW016
F1001! FUSE T1.6AL/250V or PAGC20BW3162
Ref. No. Mark Description Part No.
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
T1001! TRANS POWER BCK-28-9980 or LTTZPE0XB003
! TRANS POWER 6710 LTTZPE0KT006
Ref. No. Mark Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
----------
CONNECTOR
CN1106 242 SERIES CONNECTOR TUC-P15X-
B1 WHT ST
JCTUB15TG002
MISCELLANEOUS
JW1001 FLAT CABLE 8P AWG26#2651/P2.0/70 WX1E6820-005
JW1002 FLAT CABLE 7P AWG26#2651/P2.0/70 WX1E6820-007
Ref. No. Mark Description Part No.
JACK CBA (PSV-C)
Consists of the following:
----------
CAPACITORS
C2002 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C2004 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C2005 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C2006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2007 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C2008 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C2009 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C2010 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/ 50V M CE1JMASTM1R0
C2011 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C2021 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C2022 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTM101
DIODES
D2001 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2002 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2003 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2004 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2005 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2006 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2007 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2008 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2009 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2010 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COIL
L2003 BEAD CORE ASSEMBLY E6820ED 1VSA11351
TRANSISTORS
Q2001 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
Ref. No. Mark Description Part No.
To Next Page
