FUNAI DR-C3835 - Page 61

20060331 1-17-10 E7B22EL
AFV CBA
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q2003 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
RESISTORS
R2001 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R2002 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2003 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2004 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R2009 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2010 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2011 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2012 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R2013 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R2014 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
MISCELLANEOUS
2B12 21P EARTH PLATE E7B20ED 1VM423185
JK2001 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JW2001 FLAT CABLE 15P AWG26#2651/P2.0/70 WX1E7B20-002
Ref. No. Mark Description Part No.
A
B
AFV CBA
AFV CBA
Consists of the following:
1VSA12389
1VSA12358
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C4 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C6 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/ 16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSM100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/ 16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSM100
C16 ELECTROLYTIC CAP. 10µF/ 16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSM100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
Ref. No. Mark Description Part No.
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C20 ELECTROLYTIC CAP. 3.3µF/ 50V M H7 or CE1JMASSL3R3
ALUMINUM ELECTROLYTIC CAP 3.3µF/
50V H7
CE1JMASSM3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C22 ELECTROLYTIC CAP. 10µF/ 16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSM100
C23 A CHIP CERAMIC CAP. F Z 0.47µF/ 10V or CHD1AZ30F474
A CHIP CERAMIC CAP. F Z 0.47µF/ 16V CHD1CZ30F474
C24 ELECTROLYTIC CAP. 0.22µF/ 50V M H7
or
CE1JMASSLR22
ALUMINUM ELECTROLYTIC CAP
0.22µF/ 50V H7
CE1JMASSMR22
C27 CERAMIC CAP.(AX) F Z 0.1µF/ 50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC1 IC AUDIO PROCESSOR MSP3417G-
QG-B8-V3
NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R2 A CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R4 CHIP RES. 1/10W J 120k Ω RRXAJR5Z0124
R5 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7 A CHIP RES. 1/10W J 1.2k Ω RRXAJR5Z0122
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Mark Description Part No.
