20090826 13-8 A8CF0EL
IR SENSOR CBA
FUNCTION CBA
R714 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R717 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R718 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R720 CHIP RES. 1/10W J 39k Ω or RRXAJR5Z0393
RES CHIP 1608 1/10W J 39k Ω RRXA393YF002
R721 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R723 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R805 CARBON RES. 1/4W J 47k Ω RCX4JATZ0473
R807 CHIP RES. 1/10W J 560 Ω or RRXAJR5Z0561
RES CHIP 1608 1/10W J 560 Ω RRXA561YF002
R808 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R809 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R811 CHIP RES. 1/10W J 560 Ω or RRXAJR5Z0561
RES CHIP 1608 1/10W J 560 Ω RRXA561YF002
R813 CHIP RES. 1/10W J 39k Ω or RRXAJR5Z0393
RES CHIP 1608 1/10W J 39k Ω RRXA393YF002
R814 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R816 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R817 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R819 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R853 PCB JUMPER D0.6-P5.0 JW5.0T
R854 PCB JUMPER D0.6-P5.0 JW5.0T
R879 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R880 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R881 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R882 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R883 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R885 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R887 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R888 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
B17 MODULE HEAT SINK PMC P7150UT 1EM423968
B42 HEAT SINK PMI ASSEMBLY A71F0UH 1EM424257
BC400 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC401 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC702 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC802 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC803 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC804 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC817 PCB JUMPER D0.6-P5.0 JW5.0T
CLN400 WIRE ASSEMBLY ANALOG-INV 2PIN 2PIN/
90MM/AWG18
WX1A8CF0-006
JK202 JACK RCA PCB S 03 RCA-347HT-03 or JXRJ030YUQ01
JACK RCA PCB S MTJ-032-45BBB-25 FEL JXRJ030LY034
JK203 Y/C JACK YKF51-5646N or JYEJ040JC001
JACK SW DIN PCB S 04/DIN-417HA-01 or JYEJ040YUQ03
Ref. No. Description Part No.
JACK SW DIN PCB S 04 MDC-076H-A LF JYEJ040LY002
JK204 JACK SW RCA PCB S RCA-347HDT-02 or JYRJ030YUQ01
JACK SW RCA PCB S 03 MTJ-032-45BBA-432 JYRJ030LY029
JK205 JACK HPEP SML PCB S PJ-358H or JXSJ020YUQ01
JACK HPEP SML PCB S 02 MSJ-035-29D
(ABS)
JXSJ020LY001
JK206 JACK SW RCA PCB S RCA-228H(2)NI-01 or JYRJ020YUQ02
JACK SW RCA PCB S 02 MTJ-032-31BA-32 JYRJ020LY028
JK301 JACK RGB PCB S 21PIN / MRC-021H-02 JXGJ210LY001
JK302 JACK RGB PCB S 21PIN / MRC-021H-02 JXGJ210LY001
JK303 JACK SE HPEP SML PCM S MSJ-035-04A LF
or
JYSJ020LY002
JACK SW HPEP SML PCB S PJ-362H-7 JYSJ020YUQ02
JS651 PCB JUMPER D0.6-P5.0 JW5.0T
JS652 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JS653 PCB JUMPER D0.6-P10.0 JW10.0T
JS654 PCB JUMPER D0.6-P15.0 JW15.0T
L7 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T400! TRANS POWER 8721 LTT2PE0KT046
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C101 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C107 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
DIODES
D101 LED L-53HT or NP4Z000L53HT
LED 333HT/E-L or NPHL00333HTE
LED 333HT/E-K NPHK00333HTE
D102 LED(GREEN) LTL-4234 or NPWZ0LTL4234
LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
RESISTORS
R101 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R102 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R103 CHIP RES. 1/10W J 330 Ω or RRXAJR5Z0331
RES CHIP 1608 1/10W J 330 Ω RRXA331YF002
R104 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R105 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
MISCELLANEOUS
BC101 PCB JUMPER D0.6-P5.0 JW5.0T
RCV101 SENSOR REMOTE RECEIVER KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITORS
C109 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C110 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
DIODES
D108 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
RESISTORS
R120 CARBON RES. 1/4W G 6.8k Ω RCX4GATZ0682
R121 CARBON RES. 1/4W G 4.7k Ω RCX4GATZ0472
R122 CARBON RES. 1/4W G 2.7k Ω RCX4GATZ0272
R123 CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R124 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R125 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R126 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R127 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
SWITCHES
SW108 TACT SWITCH SKQSAB or SST0101AL038
Ref. No. Description Part No.
