FUNAI LT6-M32BB - Page 63

20090826 13-9 A8CF0EL
JUNCTION-A CBA
JUNCTION-B CBA
INVERTER CBA
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW109 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW110 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW111 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW112 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW113 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW114 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
MISCELLANEOUS
BC102 PCB JUMPER D0.6-P5.0 JW5.0T
CL102B WIRE ASSEMBLY 003 3PIN / 140MM / AWG26 WX1A8AF0-003
Ref. No. Description Part No.
JUNCTION-A CBA
Consists of the following:
----------
CONNECTOR
CN101 242 SERIES CONNECTOR TUC-P06X-B1 WHT
ST
JCTUB06TG002
MISCELLANEOUS
CL101B WIRE ASSEMBLY 6PIN 6PIN/290MM/AWG26 WX1A8CF0-007
Ref. No. Description Part No.
JUNCTION-B CBA
Consists of the following:
----------
CONNECTOR
CN804 242 SERIES CONNECTOR TUC-P04X-B1 WHT
ST
JCTUB04TG002
MISCELLANEOUS
CN803B WIRE ASSEMBLY 4PIN / 90MM / AWG26 WX1A8AF0-001
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
A8CF0MUT-001
CAPACITORS
C1000 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1001 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1002 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1003 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1004 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1005 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1006 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C1007 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C1008 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C1009 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1010 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1011 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1012 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1014 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1015 ELECTROLYTIC CAP. 470µF/35V M or CE1GMZNDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMZPDL471
C1016 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
Ref. No. Description Part No.
C1017 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1018 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1019 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1020 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1021 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1022 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1023 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1032 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C1040 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1044 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1046 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1061 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1063 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1064 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1066 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1067 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1101 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1103 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1104 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1105 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1106 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1107 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1111 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1114 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1117 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1161 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1163 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1164 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1166 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1167 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1211 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1213 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1214 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1216 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1217 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1261 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1263 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1264 CAP CERAMIC HV SL D 15pF/3KV or CCD3FJPSL150
CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1266 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1267 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1362 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1365 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1412 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1415 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1462 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1465 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
CERAMIC CAP.(AX) B 1500pF/50V CCK1JKT0B152
C1500 CHIP CERAMIC CAP.(1608) F Z 0.22µF/50V CHD1JZ30F224
C1502 CHIP CERAMIC CAP.(1608) F Z 0.22pF/50V CHD1JZ30F224
C1512 CAP CERAMIC (AX) 1500pF/50V/B/K or CA1J152TU061
Ref. No. Description Part No.
