EN - 6
3. FUNCTIONAL OVERVIEW
3.1. Front Panel
* The unit can also be turned on by pressing this button.
1. Disc tray
2. (OPEN/CLOSE) button*
3. (POWER-ON) button
4. Power-On indicator
• Flashes while unit is starting up.
• Dims and flickers when IR remote signal is received.
5. Infrared sensor window
6. USB Input
C Caution
• Do not connect any device other than USB Memory Stick or USB card reader into the USB Input. (e.g. PC, external
HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB Memory Stick, connect it directly to the USB Input. Do not use a USB extension cable.
D Note
• Due to new ENERGY STAR
®
requirements, this unit will automatically turn on the screen saver after 5 minutes of
inactivity and enter standby mode after 25 minutes of inactivity.
3.2. Rear Panel
1. AC power cord 2. HDMI OUT jack
C Caution
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the
unit.
• This unit does not have a TV RF modulator.
1342* 5 6
HDMI OUT
12
