FUNAI T3A-A8182DB - Page 16

1-7-4 E3B40DC
[18] AV CBA
[18]
AFV CBA
[17] Deck
Assembly
[19] Power SW
CBA
FE Head
Cylinder
Assembly
ACE Head
Assembly
Desolder
Lead with
blue stripe
[18] AV CBA
SW507
LD-SW
From
FE Head
BOTTOM VIEW
Lead connections of Deck Assembly and AV CBA
Desolder
From
Capstan
Motor
Assembly
Printing side
Desolder
Desolder
From
Cylinder
Assembly
From
ACE Head
Assembly
Lead with
blue stripe
Lead with
gray stripe
(S-18)
(S-19)
Fig. D8
LD-SW
Pin
Pin
Hole
Hole
Shaft
Cam Gear
[18] AV CBA
[17] Deck Assembly
Pin
