1-7-1 E3B40DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
Note:
(1): Identification (location) No. of parts in the figures
(2): Name of the part
(3): Figure Number for reference
(4): Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P=Spring, L=Locking Tab, S=Screw,
CN=Connector
*=Unhook, Unlock, Release, Unplug, or Desolder
e.g. 6(S-1) = six Screws (S-1),
5(L-1) = five Locking Tabs (L-1)
(5): Refer to “Reference Notes.
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
[1] Top Cover D1 7(S-1) ---
[2]
Front
Assembly
D2 (S-2), *5(L-1), *3(L-2) 1
[3]
Front
Bracket
D2
2(S-3A), 3(S-3B),
Front Support
---
[4]
HDD
Assembly
D3
2(S-4), *CN901,
*CN1003
---
[5]
DVD
Mechanism
&
DVD/HDD
Main CBA
Assembly
D3
2(S-5), 2(S-6),
*CN1001, *CN1502,
Dust Cover
2
[1] Top Cover
[2] Front
Assembly
[3] Front
Bracket
[21] Front
Bracket R
[22] Bracket R
[4] HDD
Assembly
[7] HDD Unit
[8] HDD
Support
[6] HDD
Bracket
[15] Front
Jack CBA
[5] DVD
Mechanism &
DVD/HDD Main
CBA Assembly
[13] Power
Supply CBA
[14] SW CBA
[10] Fan
Holder
[11] Brushless
Cooling Fan
[12] Rear
Panel
[17] Deck
Assembly
[20] Deck
Pedestal
[16] VCR
Chassis Unit
[19] Power
SW CBA
[18] AV CBA,
AFV CBA
[9] ATA CBA
[6]
HDD
Bracket
D4
4(S-7A), (S-7B), Earth
Plate
---
[7] HDD Unit D4 4(S-8), HDD Rubber 2
[8]
HDD
Support
D4 Insulation Sheet ---
[9] ATA CBA D4 *CN3001, *CN3002 ---
[10] Fan Holder D5
3(S-9A), 2(S-9B),
*CN1002
---
[11]
Brushless
Cooling
Fan
D5 ---------- ---
[12] Rear Panel D5
4(S-10A), 2(S-10B),
2(S-11)
---
[13]
Power
Supply
CBA
D6 *CL1001, 4(S-12) ---
[14] SW CBA D6 (S-13), Desolder ---
[15]
Front Jack
CBA
D6 *CN3001, 2(S-14) ---
[16]
VCR
Chassis Unit
D7
5(S-15), 4(S-16),
(S-17)
---
[17]
Deck
Assembly
D8
(S-18), (S-19)
Desolder
3
4
[18]
AV CBA,
AFV CBA
D8 ---------- ---
[19]
Power SW
CBA
D8 Desolder ---
[20]
Deck
Pedestal
D9 8(S-20) ---
[21]
Front
Bracket R
D9 (S-21) ---
[22] Bracket R D9 2(S-22) ---
(1)
(2)
(3)
(4)
(5)
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
