FUNAI T3A-A8182DB - Mechanical Parts List

20070413 1-19-1 E3B40_43_44CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
T3A-A8182DB A
T3A-D8182DB B
T3D-D8182DB C
Ref. No. Mark Description Part No.
A-1X FRONT ASSEMBLY E3B40ED 1VM222930
A-2 MAIN CHASSIS E4340UD 1VM120193P
A-3 TOP COVER(BLACK) E439AED 1VM323139
A-4 REAR PANEL E3B40ED 1VM222916
A-5 FAN HOLDER ASSEMBLY E43A0JD 1VM425152
A-7 FOOT K7010UA 0VM403657A
A-7A FOOT E6500UD 0VM416122
A-7B FOOT E6500UD 0VM416122
A-9 BARCODE LABEL UNFIGURE E9704ED ----------
A-9 A BARCODE LABEL E3B40ED ----------
A-9 B BARCODE LABEL E3B43ED ----------
A-9 C BARCODE LABEL E3B44ED ----------
A-10! A RATING LABEL E3B40ED ----------
A-10! B RATING LABEL E3B43ED ----------
A-10! C RATING LABEL E3B44ED ----------
A-11 CENTER CUSHION E4350JD 1VM422956
A-16 POWER HOLDER E434AED 1VM322233
A-25 VOID LABEL E3B40ED ----------
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E1FL
1B3 HARD DISK DRIVE WD2500BB-55RDA0 UHDD250WG001
B-1 HDD BRACKET E3A50JD 1VM222703E
B-2 MODE LENS HOLDER E4340UD 1VM422056
B-4 TAPE HIMELON(HDD) E4340UD 1VM422058
B-7 EARTH PLATE E4321JD DV-HD300 0VM414677A
B-8 DECK PEDESTAL E9600UD 1VM120055G
B-11 FRONT BRACKET E9400UD 0VM204534C
B-12 FRONT BRACKET R E9400UD 0VM416269A
B-13 BRACKET R(T3) E3A50JD 1VM424826
B-14 TAPE HIMELON H9206JD 0VM413956
B-15 RUBBER CUSHION(TOP COVER)
E4340UD
1VM422515
B-18 FRONT SUPPORT E4340UD 1VM422518
B-19 SIDE CUSHION(TOP COVER) E4340UD 1VM422517
B-20 RUBBER CUSHION (MAIN CHASSIS)
E4340UD
1VM422534B
B-21 HDD SUPPORT E3A50JD 1VM424843
B-22A HDD RUBBER E4350JD 1VM422863
B-22B HDD RUBBER E4350JD 1VM422863
B-22C HDD RUBBER E4350JD 1VM422863
B-22D HDD RUBBER E4350JD 1VM422863
B-25 CUSHION RUBBER E9400UD 0VM416664C
B-27 DUST COVER(T3) E3B90ED 1VM121092
B-32 INSULATION SHEET E3B90ED 1VM425218
FM1001 BRUSH LESS COOLING FAN
2D65BK100090
MMEZR12XNR02
L-1A SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1B SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1C SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1D SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1E SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1F SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-1G SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
L-3A SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-3B SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-3C SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-3D SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-4A SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-4B SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-5A SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
L-5B SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
L-6A SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6B SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6C SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6D SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6E SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6F SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6G SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-7A SCREW P-TIGHT 3X14 BIND HEAD + GBJP3140
L-7B SCREW P-TIGHT 3X14 BIND HEAD + GBJP3140
L-8A SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-8B SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-8C SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-9A SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9B SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9C SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9D SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9E SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9F SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9G SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9H SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9I SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9J SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9K SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9L SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9M SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9Q SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9R SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-10A SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10B SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10C SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10D SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10E SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10F SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10G SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10H SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-11A SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
L-11B SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
L-12A SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L-12B SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L-12C SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L-12D SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L-12E SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
Ref. No. Mark Description Part No.
