1-16-3 E3B40PIN
IC612 ( VFD DRIVER )
Pin
No.
IN/
OUT
Signal
Name
Function
1 IN CLK Clock Input
2 IN STB Serial Interface Strobe
3 - NU Not Used
4-NU
Ground
5- VSS
Ground
6 - VDD Power Supply
7OUT SG1
Segment Output
8OUT SG2
9OUT SG3
10 OUT SG4
11 OUT SG5
12 OUT SG6
13 OUT SG7
14 OUT SG8
15 - VEE Pull Down Level
16 OUT SG9 Segment Output
17
OUT
GR7
Grid Output
18 GR6
19 GR5
20 GR4
21 GR3
22 GR2
23 GR1
24 - VDD Power Supply
25 - VSS
Ground
26 IN OSC Oscillator Input
27 - NU Not Used
28 IN DIN Serial Data Input
