FUNAI T3A-A8182DB - Page 74

20070413 1-20-2 E3B40_43_44EL
C453 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C454 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C455 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C456 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C457 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C458 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C461 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C462 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C463 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C464 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C465 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C466 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C468 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C469 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C470 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C471 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C472 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C473 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C474 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C475 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C476 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C478 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C479 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C480 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C481 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C482 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C483 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C484 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C485 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C486 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C487 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C488 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C502 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V
CHD1JK30B223
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C506 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C507 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C509 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C510 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C511 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C514 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C515 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C516 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C517 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C518 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C519 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C521 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C522 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C524 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C527 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
Ref. No. Mark Description Part No.
C531 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C533 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V
CHD1JK30B473
C534 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C535 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C536 C CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C538 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C539 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C540 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C541 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C542 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C545 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C546 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C547 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C549 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C550 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C553 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C554 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C555 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V
CHD1EK30B104
C558 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C611 ELECTROLYTIC CAP. 22µF/50V M H7 CE1JMASSL220
C612 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C614 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C616 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1501 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1502 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1503 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1504 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
If C1505 is 0.015µF, then IC1502 is R3112N211A-TR-F or BU4221G-TR.
C1505 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
IC1502 VOLTAGE DETECT R3112N211A-TR-F or QSZBA0TRC026
RESET IC BU4221G-TR QSZBA0TRM102
If C1505 is 0.15µF, then IC1502 is PST3621NR.
C1505 CHIP CERAMIC CAP.(1608) B K 0.15µF/
25V
CHD1EK30B154
IC1502 SYSTEM RESET IC PST3621NR QSZBA0TMM162
C1506 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1507 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1509 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1511 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1512 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1513 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1515 ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASDL470
C1518 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1519 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1520 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1521 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1522 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1524 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
Ref. No. Mark Description Part No.
