FUNAI T3A-A8182DB - Page 84

20070413 1-20-12 E3B40_43_44EL
POWER SW CBA
SENSOR CBA
PW/SW CBA
POWER SUPPLY CBA
XTAL 1K*044334EE FXC445LDS002
X501 QUARTS CRYSTAL 12.000000MHz or FXD126LCHE01
XTAL 12MHz 12.000MHz FXD126LDS002
X1501 RESONATOR XTAL 32.768kHz QTF38-
32.768K125P15L or
FXC323LQUA03
XTAL DT38 32.768kHz FX0323LDS001
X1502 QUARTZ CRYSTAL C49SJJ11640-
10.000M or
FXD106LLN002
RESONATOR XTAL 10MHz AT-49 10MHz FXE106LDS001
Ref. No. Mark Description Part No.
POWER SW CBA (AV PCB B)
Consists of the following:
----------
DIODE
D1602 LED(RED) 1254IT NPQZ0012541T
SWITCHES
SW1601 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
W6 PARALLEL WIRE 4P AWG26#2651/
126MM
WX1E4340-006
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
1VSA13519
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
PW/SW CBA
Consists of the following:
1VSA15762
POWER SUPPLY CBA (PW/SW-A)
FRONT JACK CBA (PW/SW-B)
SW CBA (PW/SW-C)
REAR JACK CBA (PW/SW-D)
----------
----------
----------
----------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PW/SW-A)
Consists of the following:
----------
CAPACITORS
C013 ELECTROLYTIC CAP 470µF/50V M or CE1JMZADL471
ELECTROLYTIC CAP 470µF/50V M CE1JMZPDL471
C014 ELECTROLYTIC CAP. 470µF/25V M CE1EMASDL471
C020 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C022 ELECTROLYTIC CAP. 470µF/35V M CE1GMASDL471
C1001! ACROSS THE LINE CAP. 0.068µF/250V
or
CT2E683DC016
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C1004 ELECTROLYTIC CAP. 220µF/400V M or CA2H221S6029
ELECTROLYTIC CAP. 220µF/400V M CA2H221NC084
C1006! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C1029 CERAMIC CAP. B K 150pF/2KV CCD3DKP0B151
C1030 POLYESTER FILM CAP. (PB FREE)
0.068µF/100V J or
CA2A683DT018
FILM CAP.(P) 0.068µF/50V J or CA1J683MS029
FILM CAP.(P) 0.068µF/100V J CMA2AJS00683
C1034 FILM CAP.(P) 0.039µF/50V J or CA1J393MS029
FILM CAP.(P) 0.039µF/100V J CMA2AJS00393
Ref. No. Mark Description Part No.
C1035 ELECTROLYTIC CAP. 3300µF/6.3V SL or CE0KMZADL332
ELECTROLYTIC CAP. 3300µF/6.3V SM CE0KMZPDL332
C1036 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471
C1037 ELECTROLYTIC CAP. 2200µF/25V SL or CE1EMZADL222
ELECTROLYTIC CAP. 2200µF/25V M CE1EMZPDL222
C1039 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1100 POLYESTER FILM CAP. (PB FREE)
0.0068µF/100V J or
CA2A682DT018
FILM CAP.(P) 0.0068µF/50V J or CA1J682MS029
FILM CAP.(P) CQ921M2A682 CMA2AJS00682
C1102 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471
C1104 ELECTRIC CAP. 4700µF/10V or CE1AMZADL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C1105 ELECTRIC CAP. 4700µF/10V or CE1AMZADL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C1107 ELECTROLYTIC CAP. 2200µF/10V SL or CE1AMZADL222
ELECTROLYTIC CAP. 2200µF/10V M CE1AMZPDL222
C1110 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1112 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1113 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1114 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1115 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1116 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1117 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1118 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1119 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1121 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1126 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1127 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1128 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1129 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1130 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1131 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1132 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1133 POLYESTER FILM CAP. (PB FREE)
0.001µF/100V J or
CA2A102DT018
FILM CAP.(P) 0.001µF/50V J or CA1J102MS029
FILM CAP.(P) 0.001µF/100V J CMA2AJS00102
C1138 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1139 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1140 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1141 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1142 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1143 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
CONNECTORS
CN1001 FFC CONNECTOR 30PIN IMSA-9615S-
30A-PP-A or
JC96J30ER007
FFC CONNECTOR 30PIN 00 6232 030
006 800+
JC62G30UG026
CN1002 PH CONNECTOR (WHITE) TOP 2P B2B-
PH-K-S(LF)
J3PHC02JG017
DIODES
D012 RECTIFIER DIODE BA158 or NDQZ000BA158
DIODE FAST RECOVERY BA158 or NDLZ00BA158S
RECTIFIER DIODE BA158 NDWZ000BA158
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
DIODE FAST RECOVERY BA158 or NDLZ00BA158S
RECTIFIER DIODE BA158 NDWZ000BA158
D014 SCHOTTKY BARRIER DIODE SB390 or NDQZ000SB390
DIODE SCHOTTKY SB390 or NDLZ00SB390S
SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D015 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
Ref. No. Mark Description Part No.
