Furrion FSCC60PW2 User Manual

CCD-0007727 Rev: 06-01-23
- 12 -
Installation
English
For a single Furrion 165W solar panel (PN: FSFP16MW2-BL) the voltage at max. power is 17.9V, current
at max. power is 9.7A and the max. power is 165W.
After connecting two panels in series conguration,
The resultant array’s voltage at max. power will be 35.8V, current at max. power is 9.7A and total max.
power of the array is 330W.
The Furrion MPPT technology based solar charge controller can function eciently and convert
almost 98% of its input solar power into charging power with the help of the added voltage resulting
from a series connection of solar panels. The wire gauge of the array can remain the same, as series
conguration will keep the output current same as a single panel. Hence, it is recommended to
connect solar panels in series conguration in an array when using the MPPT solar charge controller.
When connecting solar panels in an array, care must be taken so that the resultant array voltage and
power parameters do not exceed the charger specications shown below.
Model
Parameter 40A charger (FSCC40PW2) 60A charger (FSCC60PW2)
Maximum input PV power 520W 750W
Maximum PV Open Circut
Voltage
(V
OC
)
95V 95V
Wire Size and Fuse Recommendations
● Wiring and installation methods must comply with national and local electrical code/
specications.
● The wiring specications of the PV and battery system must be selected according to the rated
currents specied.
● Since the PV outputs can vary due to the array connection method, the minimum wire size must
be in accordance with the maximum array short-circuit current.
● Please use PV Photovoltaic wire for connection of the array to the charge controller.
● It is recommended to install a fuse between the charger and the battery on the positive wire.
Location of the fuse should be closer to the battery. The fuse rate must be 1.2 - 1.5 times more
than the maximum rated charge current of the solar charge controller.
Please check the following table for wiring specications:
Model Rated charge
current
PV Wire Gauge
(AWG)
Battery Wire
Gauge (AWG)
Rated Discharge
current
(Load terminals)
Load terminal
wire Gauge
(AWG)
40A charger
(FSCC40PW2)
40A 10 8 30A 10
60A charger
(FSCC40PW2)
60A 8 6 30A 10
