Furrion FURRIONNET-ZERO FSCC60PWM-BL User Manual

10
Installation
English
Battery
+ -
- +
Breaker
Fuse
PV
array
- +
PV
array
Fuse
P/N: FSFP16MW-BL P/N: FSFP16MW-BL
Temperature Sensor
P/N: C-FSCC60PW-A01,
C-FSCC60PW-A02
P/N: FBF12A100E
Furrion Solar Connector
P/N: FSEB30JWP-BL
MPPT Solar Charge Controller
25A version
P/N: FSCC30PW-BL
+
-
-
+
Rooftop Solar
Electrical Box
P/N: FSEB30JWL-BL
Fig. 9
NOTE: If the battery cable is connected to the
50A port by RV manufacturer, a 25A MPPT
controller will work without moving the
wiring to the 25A port.
- +
Breaker
Fuse
- +
Fuse
Rooftop Solar
Electrical Box
- +
PV
array
- +
PV
array
P/N: FSFP16MW-BL P/N: FSFP16MW-BL
P/N: FSEB30JWL-BL
Furrion Solar Connector
P/N: FSEB30JWP-BL
Battery
+ -
Temperature Sensor
P/N: C-FSCC60PW-A01,
C-FSCC60PW-A02
P/N: FBF12A100E
MPPT Solar Charge Controller
50A version
P/N: FSCC60PW-BL
+
-
-
+
Fig. 10
