xii
Two-unit NavNet system
Two-unit NavNet system
Three-or-more-unit NavNet system (Max. 4 display unit and one network sounder
capable display units)
HUB
Network Sounder
ETR-6/10N
ETR-30N
(option)
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
RADAR
or
PLOTTER
RADAR
or
PLOTTER
Sounder data
Radar data
Plotter data
Note: The picture disappears
10 seconds after the NavNet
cable is disconnected from a
"sub" NavNet display unit.
Network Sounder
ETR-6/10N
ETR-30N
(option)
Facsimile
Receiver
FAX-30
(option)
Sounder data
Facsimile data
Three-or-more-unit NavNet system
