SYSTEM CONFIGURATION
Display Unit (MU-150HD, etc.)
(2 max.)
Processor Unit
CSH-5210-A
Control Unit
CSH-5211-A
Navaid
Current Indicator
AD Converter
Speed Log
E/S Interface
Remote Controller
Speaker
Hull Unit
CSH-8040-A,
600 mm stroke
CSH-8041-A,
400 mm stroke
: Standard supply
: Option/User supply
Transceiver Unit
CSH-8030-A-8L
Motion Sensor
MS-100
100/115/200/220/240 VAC
1ø, 50 - 60 Hz
DC/AC
Inverter
TR-2451
24/32 VDC
Junction Box
CSH-1700
Ship's Mains
