SYSTEM CONFIGURATION
Antenna unit
FB-1500 (FELCOM 500)
FB-1250 (FELCOM 250)
Communication unit
FB-2000
IP Handset
FB-8000
Incoming indicator
FB-3000
Network Equipment
(See Caution on next page.)
G3 facsimile
Analog telephone
Analog telephone
Analog telephone
Navigation equipment
External alarm
PC or Router
AC-DC
Power supply
PR-240
12-24 VDC
A
C100-115/
200-230V
LAN(4)
TEL(4)
RS-232C
NMEA
Antenna unit
Communication unit,
IP handset, etc.
Environmental Category
To be installed in an exposed area
To be installed in a protected area
Normal Close
PC
