5. WEB SOFTWARE
5-2
5.2 Screen Explanation
The screen is divide into several areas.
Status area
The status area displays the reception signal level, ship position information, date and
time. Data is updated every 30 seconds.
Sub menu area Information area
Status area
Administrator login/
logout button.
䋨
Refer to 5.9.1, 6.1.1
䋩
Menu bar System message area
See “IMPORTANT NOTICES” (page i).
Reception signal level (8 bars)
Date Time
Ship latitude Ship longitude
