Furuno MFD12 Installation Manual

v
Cable Assy MOD-Z072-020+ 000-167-175-10 LAN cross, 4-pair, 2 m
MOD-Z072-050+ 000-167-176-10 LAN cross, 4-pair, 5 m
MOD-Z072-100+ 000-167-177-10 LAN cross, 4-pair, 10 m
MOD-Z073-030+ 000-167-171-10 LAN straight, 2-pair, 3 m
MJ-A6SPF0016-005C 000-159-689-11 For FAX-30, ETR6N/10N con-
nection
NMEA Connector LTWSS050505FMF-
TS001
000-168-603-10 NMEA 2000 distributor, micro
style
LTWMC-05BMMT-
SL8001
000-168-604-10 NMEA 2000 terminator, male,
micro style
LTWMC-05BFFT-
SL8001
000-168-605-10 NMEA 2000 terminator,
female, micro style
LTWNC050505FMF-
TS001
000-160-507-10 NMEA 2000 distributor, mini
style
LTWMN-05AMMT-
SL8001
000-160-508-10 NMEA 2000 terminator, mini
style
LTWMN-05AFFT-
SL8001
000-160-509-10 NMEA 2000 terminator,
female, mini style
In-line Terminator
FRU-0505-FF-IS
000-172-037-10 NMEA 2000 connector w/ter-
minator, micro style
DVI-D Cable DVI-D/D SINGLELINK 000-149-054-10 5 m, for Multi-purpose LCD
connection
DVI-D/D S-LINK 000-150-200-10 10 m, for Multi-purpose LCD
connection
External Buzzer OP03-136 000-086-443
Junction Box FI-5002 000-010-765 For FI-50 series connection
Rectifier RU-3423 000-030-443 w/o PSU-012
PR-62 000-013-484 100VAC, w/PSU-012
000-013-485 110VAC, w/PSU-012
000-013-486 220VAC, w/PSU-012
000-013-487 230VAC, w/PSU-012
RU-1746B-2 000-030-439 220VAC
-For PSU-012 and MFD
-PSU-013
Network Hub HUB-101 -
Joint Box TL-CAT-012 000-167-140-10 For LAN cable extension
Connector Boot OP19-7 001-028-090
Operator’s Manual OME-4440 000-167-802
NMEA 2000 Inter-
face Unit
IF-NMEA2K1 -
Name Types Code No. Remarks
