Furuno NAVNET 1824C - Page 216

APPENDIX
A
P-3
PORT
SETUP
2
4
SYSTEM
SETUP
3
SELECT SNTNC soft key*
PORT MNITR soft key*
DATA 1:
GPS/NMEA
PORT
OUTPUT FORMAT
(NMEA 0183 Ver.1.5, 2.0)
LAT/LON FORMAT
(DD° MM. MM'
DD° MM. MMM'
DD° MM. MMMM')
XTE FORMAT (X.XX, X.XXX)
OUTPUT DESTINATION
(YES, NO)
OUTPUT THROUGH NETWORK
(Select data sentences to output to NavNet
equipment. See * below. All sentences turned off in default setting.)
DATA 3:
PC/NMEA/
EXT. BUZZ
PORT
NMEA OUTPUT FORMAT
(NMEA Ver.1.5, 2.0)
BAUD RATE
(4800, 19200 bps)
BIT LENGTH (7 bits, 8 bits)
STOP BIT (1 bit, 2 bits)
PARITY
(EVEN, ODD, NONE)
SELECT SNTNC soft key*
PORT MNITR soft key*
* = AAM, APB, BOD, BWR(BWC)#1, DPT(DBT)#2, GGA, GLL, GTD,
MTW, RMA, RMB, RMC, VHW, VTG, WPL, XTE, ZDA, HDT, HDG, MWV, ZTG, TTM
DATA 2:
NMEA PORT
OUTPUT FORMAT
(NMEA 0183 Ver.1.5, 2.0)
BAUD RATE
(AUTO, 4800 bps, 38400 bps)
LAT/LON FORMAT
(DD° MM. MM'
DD° MM. MMM'
DD° MM. MMMM')
XTE FORMAT (X.XX, X.XXX)
OUTPUT DESTINATION
(YES, NO)
#1= BWR for rhumb line, BWC for great circle
#2 = DBT for NMEA Ver. 1.5; DPT for NMEA Ver. 2.0
CLEAR WINDOW
SELECT SNTNC soft key*
PORT MNITR soft key*
CLEAR WINDOW
CLEAR WINDOW
(except in case of OUTPUT THROUGH NETWORK)
