APPENDIX
AP-4
* = Requires GPS Receiver GP-310B/320B.
** = Requires Network Sounder ETR-6/10N, ETR-30N.
*** = Requires ARP-equipped Model 18X4/19X4 series network radar.
3
DATA
TRANSFER
UPLOAD/
DOWNLOAD
DATA
RECEIVE YEOMAN DATA (Receive Yeoman data.)
DOWNLOAD WPT/ROUTE TO PC
(WAYPOINTS & ROUTES,
MARKS & LINES)
UPLOAD WPT/ROUTE FROM PC
(WAYPOINTS & ROUTES,
MARKS & LINES)
SAVE DATA TO MEMORY CARD
(TRACKS, MARKS & LINES,
WAYPOINTS & ROUTES,
SETTING DATA)
LOAD DATA FROM MEMORY CARD
(TRACKS, MARKS & LINES,
WAYPOINTS & ROUTES,
SETTING DATA, WALLPAPER)
RECEIVE DATA
VIA NETWORK
HOST NAME (NAVNET1, 2, 3, 4)
MARKS & LINES (ON, OFF)
WAYPOINTS & ROUTES (ON, OFF)
4
TEST &
CLEAR
MEMORY
I/O TEST
HOT PAGE
& NAV DISP
SETUP
HOT PAGE SETUP (Configures HOT PAGE 1 to 6.)
RADAR (BUILT IN DATA 1, BUILT IN DATA 2, USER DATA, LIVE)
PLOTTER (SIMULATION, LIVE)
SOUNDER (BUILT IN DATA, ETR DATA, LIVE)
SPEED (0.0-99.9 kt)
COURSE (8 FIGURE, DIRECTION 0.0-359.9°)
LATITUDE (90°0.0'N-90°0.0'S)
LONGITUDE (180°0.0'E-180°0.0'W)
START DATE & TIME (hh: mm dd. mmm. yy)
GET RADAR SIMULATION DATA (YES, NO)
NAV DATA DISPLAY SETUP (Configures nav data displays.)
TEST PATTERN
MEMORY
CLEAR
KEYBOARD & REMOTE TEST
DISPLAY UNIT (YES, NO)
GPS SENSOR (YES, NO)*
NETWORK SOUNDER (YES, NO)**
DISPLAY UNIT TEST
GPS SENSOR TEST*
NETWORK SOUNDER TEST**
ARP TEST***
SIMULATION
SETUP
SELECT BPS soft key
4800
9600
19200 (bps)
NAV GRAPHIC DISPLAY SETUP
GRAPHIC METER (COMPASS, WIND ANGLE)
DEPTH GRAPH UP-DATE (0.5, 1, 2, 4 s/dot)
TEMP GRAPH UP-DATE (0.5, 1, 2, 4 s/dot)
To Next Page
