3. SETTING UP THE EQUIPMENT
This chapter shows you how to set up your system according to the equipment you have connect-
ed. To do this more easily the Installation Wizard is provided. It has all the items necessary for
setting up your system.
The flow chart of Installation Wizard is shown below.
Flow chart when one MFD (Multi Function Display) is installed
Installation setting
end
DHCP*/installation setting
start
Turn on the MFD.
Installation Wizard starts.
Set language.
MFD automatically
turns off.
DHCP server setting
is completed.
Installation setting
start
Turn on MFD again.
Installation Wizard starts.
Own tab setting
(Setting, NMEA2000 port
and NMEA0183 port
dialog boxes)
Global tab setting
(Generic, Analog Display,
Nickname, Camera name and
Data Source dialog boxes)
Turn off MFD.
Sounder and Radar setting
(when network sounder(s)
and/or DRS is connected)
Designate an MFD as
DHCP server.
Turn on the MFD.
*Dynamic Host
Configuration
Protocol
To Next Page
