21
16.Click the Next button.
Global tab-Generic dialog box
Enter your boat’s dimensions and select length/width unit.
Disable Satellite Every GPS satellite is broadcasting abnormal satellite number(s) in its Alma-
nac, which contains general orbital data about all GPS satellites, including
those which are malfunctioning. Using this information, the GPS receiver
automatically eliminates any malfunctioning satellite from the GPS satellite
schedule. However, the Almanac sometimes may not contain this information.
If you hear about a malfunctioning satellite from another source, you can dis-
able it manually. Enter satellite number (max. 3 satellites) in two digits.
INIT. Position Set initial latitude/longitude position for cold start.
ANT. Position Enter the GPS antenna positioning bow-stern and port-starboard position.
ANT. Height Enter the height of the GPS antenna unit above sea surface.
Rx Mode Choose position fixing method: 2D (three satellites in view), 2D/3D (three or
four satellites in view whichever is greater).
WAAS Mode Select ON to use the WAAS mode.
WAAS Search WAAS satellite can be searched automatically or manually. For manual
search, enter appropriate WAAS satellite number.
WAAS Alarm When the WAAS signal is lost, the audible alarm sounds one of two ways.
On: Alarm sounds continuously until the WAAS positioning mode is available
again or the alarm is acknowledged (by key operation). Off: Alarm sounds
three times.
Menu item Description
