2. INSTALLATION
6
9. Put the release lever in the backward position. Turn the platen knob clockwise to feed the pa-
per so it reaches the paper guide bar.
10. Adjust the inclination of the paper if necessary. Pull the release lever forward to adjust the pa-
per and then lock it. Move the guide ring (left/right) gently to hold the paper.
11. Remount the paper cover and the printer cover.
12. Turn the power on.
Paper guide bar
Platen
Platen knob
Guide ring
Release lever
