3. EQUIPMENT SETUP
3-8
[DATA ACQUISITION] menu
[NMEA2000 Log] menu
[SC-30 SETUP] menu
This menu is only available with SC-30 connection.
[NETWORK SENSOR SETUP] menu
The [NETWORK SENSOR SETUP] section allows you to set up compatible FURUNO
NMEA 2000 sensors. Calibrations and offsets applied in this menu are also applied to
the sensor itself.
Tap the sensor to access its menus and settings. For details regarding the menu struc-
ture and set up of each sensor, see the appropriate operator’s manual, supplied with
the sensor.
[Factory Reset] Resets the converter selected at
[Select IF] to factory default.
[OK], [Cancel]
Menu Item Description Options (setting range)
[GP330B WAAS Mode] Select [ON] to use the WAAS mode for the
corresponding GPS antenna.
[OFF], [ON]
[WS200 WAAS Mode]
[Data Source] Select the source for each data to input to the system. If two or more
sources are connected for a data, select one using the pull-down dialog
box. The FURUNO products are shown at the upper part of the list.
[Sensor List] Show the information for sensors connected to your equipment. Also,
you can set “Nickname” for them here.
[NMEA0183 Output]
Note: If the TTM sentence
is received at the same
time as another sentence,
the constraints to commu-
nication bandwidth may
cause a decrease in the
number of TTM targets.
[Port Configuration] - [Baud Rate]: Select
the output baud rate.
[4,800], [9,600], [38,400]
[Port Configuration] - [NMEA-0183 Ver-
sion]: Select the NMEA 0183 version for
output.
[1.5], [2.0], [3.0]
[Sentences]: Select the sentences to out-
put.
[OFF], [ON]
[NMEA2000 PGN Output] Select [ON] for the PGN's (Parameter Group Number, NMEA 2000
message) to output from the NMEA 2000 port.
Note: The default setting of some PGN’s is “ON”.
[Sky View] Show the condition of GPS and GEO (WAAS) satellites. Number, bear-
ing and elevation angle of all GPS and GEO satellites (if applicable) in
view of your GPS receiver appear.
Menu item Description Options (setting range)
[Enable NMEA
2000 Log]
Enable or disable saving of NMEA 2000 data. [OFF], [ON]
[NMEA2000 Log
Storage Location]
Select where to save NMEA 2000 data.
Menu item Description Options (setting range)
[WAAS Mode] Select [ON] to use the WAAS mode. [OFF], [ON]
[Heading Offset] Enter the offset value for heading. -180° to +180°
[Pitch Offset] Enter the offset value for pitching. -90° to +90°
[Roll Offset] Enter the offset value for rolling. -90° to +90°
Menu item Description Options (setting range)
