3. EQUIPMENT SETUP
3-7
[INSTRUMENTS SETUP] menu - Engine & Tank, Graphic Instruments menus
Engine & Tank, Instruments Setup
[YAMAHA ENGINE SETUP] menu
[IF-NMEAFI SETUP] menu
Menu item Description Options (setting range)
[Engine & Tank Auto-
matic Setup]
See page 3-11.
[Engine & Tank Manual
Setup]
See page 3-11.
[Graphic Instruments
Setup]
See page 3-10.
Menu item Description Options (setting range)
[Trip & Mainte-
nance]
Reset fuel used, trip distance, engine trip and
maintenance hours (trip hour, standard hour,
optional hour, total hour).
[Trip Fuel & Distance]: [Fuel
Used], [Trip Distance].
[Trip & Maintenance Hours]:
[Port], [Starboard].
[Trim Level Calibra-
tion]
Trim all engines to fully down position (zero).
If trim level is not zero, tap [SET] to set trim
level to zero.
–
[Fuel Flow Calibra-
tion]
If the fuel flow indication (gph=gallons per
hour) is wrong, you can calibrate the indica-
tion to show correct flow. Enter a negative val-
ue if the indication is higher than actual; a
positive value if the indication is lower than ac-
tual.
-7 to +7
[Engine Interface
Software Ver. & ID]
Display engine interface software version and
ID.
–
[Reset Engine Inter-
face]
Reset engine interface. –
[Reset Engine In-
stance]
Reset engine instance. –
[Reset Number of
Engines]
Enter number of engines. [1], [2], [3], [4], [4P], [4S]
[Trouble Codes] Display trouble codes. See the operator’s
manual for the Yamaha engine for details.
–
Menu item Description Options (setting range)
[Select IF] Select [IF-NMEAFI] to set the analog data that is input from the IF-NMEAFI.
The setting is made after restarting the IF-NMEAFI.
[Category] Select the use (category) for this sensor. [Wind], [ST800_850], [Fuel],
[FreshWater], [WasteWater],
[LiveWell], [Oil], [BlackWater]
[Resistance Full] The resistance, in Ohms, when the tank is full. 0 (Ohm) to 500 (Ohm)
[Resistance Mid] The resistance, in Ohms, when the tank is half
full.
0 (Ohm) to 500 (Ohm)
[Resistance Empty] The resistance, in Ohms, when the tank is
empty.
0 (Ohm) to 500 (Ohm)
[Capacity] The capacity of the tank. 0 (G) to 2650 (G)
[Fluid Instance] Set the tank’s NMEA 2000 instance number. 0 to 5
[Self test] Test results are displayed.
