Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 23 of 44 Issue 02
Joint:97 [ /233C]
Auto trim cycle
Trimming
PE63 250 SDR11
Please wait
The system will then gradually increase the system pressure to move the pipes
onto the trimmer in a controlled manner. When a small amount of pipe has been
trimmed from the pipe ends, the display will indicate:
Joint:97 [ /233C]
Auto trim cycle
Feathering off to finish
PE63 250 SDR11
When the green button is actuated, the LCD display will indicate “feathering off to
finish” while the pipe ends are being finely “feathered”, to avoid a step on the pipe
end.
The motor will stop and the display will indicate that the trim cycle is complete.
The machine will open and the prompt:
Joint:97 [ /233C]
Auto trim cycle
Remove the trimmer to continue
PE63 250 SDR11
Unlock the trimmer by turning the twist locks anti-clockwise. Remove the trimmer
and carefully replace it into the heater/trimmer stand. As the trimmer is removed,
a short audible tone will be heard. The machine is now ready for the pipe slippage
and alignment check stage.
Once the trimmer has been removed, clear all swarf away from the pipe ends. It is
good practise to remove the swarf from the bottom of the chassis to avoid
dragging contaminants over the trimmed pipe ends.
When the swarf has been removed check the pipe ends to ensure that the
surfaces are sufficiently trimmed and free from dirt and defects. If the surfaces are
unsatisfactory; press the red button to return to the trimming stage.
Warning! Take extreme care not to touch the pipe ends at this stage and as soon
as the pipes have been checked, proceed to the next stage.
