Gator Au
tomatic Butt Fusion
Range
Operating
Manual
EDOI6922
Page 6 of
44
Issue 02
2 Getting to kn
ow y
our Gator
The four main components of the Automatic Butt Fusion Machine:
2.1 Controller
The controller keypad is located under the protective cover of the control unit lid.
Display
Close button
Down button
Start
or
enter
button
Right button
Alarm
warning
light
BlueBox LED’s
Input
v
oltage
warning light
Up button
Return button
Left button
Open button
Chassis
Automatic
Control Unit
Trimmer
Heater
5
7
