Fusion Gator Series User Manual

Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 38 of 44 Issue 02
15 Specification
Supply
Gator 180, 250 & 315
Minimum
Typical
Maximum
Input voltage 110V
97v
110v
150v
220V
195v
230v
265v
Input frequency
40Hz
50Hz
60Hz
Power requirements
180
250
315
Trimmer
750 watt
750 watt
750 watt
Heater
1500 watt
1800 watt
3300 watt
Controller
1200 watt
1200 watt
1200 watt
Generator
3.5 KVA
4 KVA
6 KVA
Note: Due to software control, the maximum power demand = Heater + Controller.
Environment
Gator 180, 250 & 315
Minimum
Maximum
Operating temperature
-10°C
+40°C
Storage temperature
-15°C
+45°C
Environmental protection
IP54
Pipe & joining parameters
Gator 180, 250 & 315
Minimum
Maximum
Diameter range Gator 180
63mm
180mm
Gator 250
63mm
250mm
Gator 315
90mm
315mm
Joining pressure
10Bar
60Bar
Heater removal time
1.3s
3.5s
Heater temperature 110V
233°C
Heater temperature 220V
205°C, 210°C, 215°C, 220°C, 225°C & 233°C
SDR range
7.25, 7.4, 9, 11, 13, 13.6, 17, 17.6, 21 26, 33, 67
Welding standards
DVS2207-1
WIS4-32-08
GIS/PL2-3 (GB)
Osaka Gas
Japan
Toho Gas
S/EM-044-E Part 1
UK WIR 90°C Fastweld
Fusion FW Landfill
DVS-215°C
DS/INF (Insta)
DVS2207-11 Polyprop.
UNI 10520
Gaz du France
Mesco
UNI 10967
TSG
HKCG (BG)
ISO21307 SLP
ISO21307 DLP
Joining sequence details
Gator 180, 250 & 315
Automatic
Manual
Trim

Check (slippage)

Check (Alignment)

Bead-up phase

Soak phase

Heater removal

Pressure build-up

Fusion phase

Cooling phase

