Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 32 of 44 Issue 02
13.3 Output joint record(s) (Menu option 02)
Selecting this option allows the operator to view joint data on the screen or
download joint data to memory stick. View downloaded joint data in Microsoft
®
Notepad from output joint records option.
Review joint(s)
Send to: Screen
Select record(s):
Last joint
From 24
To 24
● to Proceed
13.3.1 Send to
First use the up and down buttons to select ‘Send to’ then using the left and right
buttons to select the destination for the joint data.
13.3.2 Screen
Display the joint data on the screen. See section 13.3.6 select record(s)
view/download.
13.3.3 Printer
Send joint data to thermal printer. Connect printer to green printer socket on the
rear of the computer. See section 13.3.6 select record(s) review/print.
13.3.4 USB drive
Down loads the joint data to memory stick so the data can be viewed in Notepad
(Unicode Font must be used). Connect the memory stick to the USB ‘A’ connector
on the rear of the computer. See section 13.3.6 select record(s) view/download.
13.3.5 PC
Down loads the joint data to PC so the data can be viewed in Notepad. Connect
the green plug on the universal data transfer lead to the green printer socket on
the rear of the computer and connect the other end of the universal data transfer
lead to the serial port of the PC. See section 13.3.6 select record(s) review/print.
13.3.6 Select record(s) view/download
Using up and down buttons scroll to ‘Last joint’. Using the left and right buttons
select the required joint selection choosing from.
13.3.6.1 Last joint
This gives the last joint fused. See section 13.3.6.7 sending data view/download.
13.3.6.2 All joints
This gives all the joints in the database. See section 13.3.6.7 sending data
view/download.
