Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 33 of 44 Issue 02
13.3.6.3 Joint range
Allows a range of joints to be selected by scrolling down to ‘From’ or ‘To’ then
using the left and right buttons on the keypad to select the joint range. See section
13.3.6.7 sending data view/download.
13.3.6.4 All complete
This gives all the complete joints in the database. See section 13.3.6.7 sending
data view/download.
13.3.6.5 All incomplete
This gives all the incomplete joints in the database. See section 13.3.6.7 sending
data view/download.
13.3.6.6 Matching criteria
This gives joint data for an operator and/or project by scroll to operator or project
press green button to enter criteria the following screen will be displayed.
Operator
---------------------------------------
A B C D E F 1 2 3
G H I J K L 4 5 6
M N O P Q R 7 8 9
S T U V W X , 0 .
Y Z ⌴ + -
Scroll to the appropriate character using the up, down, left and right buttons on
the keypad. Then press the green button on the keypad to select the character.
For more information see section 5.1 character entry screen. If no match is found
the following screen is displayed:
See section 13.3.6.7 sending data view/download.
13.3.6.7 Sending data view/download
When the required joint selection has been made scroll down to ‘● to proceed’
then the relevant information will be given.
If the destination is the screen one joint at a time will be displayed. Use the up and
down buttons on the keypad to scroll up and down the joint data. Press the green
button to tab across to see the information that runs off the side of the screen.
Use the left and right button to move on to the next joint. Press the red button on
the keypad to exit.
When joint data has been sent to USB drive the screen will display complete
‘press ● to continue’. The status bar at the bottom of the screen will show the
status of the download see section 9 status bar.
Operation cancelled:
No matching record
Press ● to continue
