Fusion Gator Series User Manual

Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 27 of 44 Issue 02
11.4.4 Automatic pressure build-up
When the molten pipe ends come into contact with each other, the pressure builds
up to the target welding pressure plus the drag pressure value measured
previously.
11.4.5 Automatic Fusion and cooling stage
The automatic fusion and cooling stages allow the joint to form and become solid
before the clamps can be removed. During these stages, the display shows:
Joint:97 [  /233C]
Fusion
Target pressure 10Bar
Achieved pressure 10Bar
Time remaining 578seconds
PE63 250 SDR11
11.5.6 Accepting the joint
When the joint is complete the machine will prompt the operator for the bead to be
inspected by showing the following:
Joint:97 [  /233C]
Is final bead OK
PE63 250 SDR11
If the bead is okay, press the green button. If not, press the red button.
Finally, the display will show:
Joint:97 [  /233C]
Joint 97 complete
PE63 250 SDR11
Pressing the green button will prompt for entry of an operator code to start the
next joint.
Manually aborting the cycle
At any stage the jointing cycle can be aborted by pressing the emergency stop
button, this should only be in emergencies.
