Gator Automatic Butt Fusion Range
Operating Manual
EDOI6922 Page 22 of 44 Issue 02
the two pipes are aligned and placed to the top of the machine.
To secure the pipe, place the clamp over the pipe and raise the edge to ensure
that the clamp adjusters are hooked under, onto the clamp. The clamp should
then be firmly pushed onto the pipe and the fast-clamp toggle levers (1) placed
over the edge of the clamp it may be necessary to release the clamp adjusters (2)
– particularly on oval pipe. When fastening the pipe into the machine, the toggle
levers should be set so that only a reasonable force needs to be applied to fasten
the toggle lock.
As a guide when fastening, the fast clamp levers should be lifted in the direction
indicated and the clamp adjusters moved until the lever is in a vertical position –
the levers may then be pushed onto the top clamp. Note that the adjusters should
only be moved when the fast-clamp levers are in the released position.
11.2.5 Trim Cycle
When the pipes have been secured in place, press the green button and the
machine will start the trimmer motor. The LCD will display:
Joint:97 [ /233C]
Auto trim cycle
PE63 250 SDR11
Please wait
The machine will open and then tune the trimming parameters for around 5
seconds indicating:
Joint:97 [ /233C]
Auto trim cycle
Tuning trim parameters
PE63 250 SDR11
Please wait
The software control monitors the trimmer and if certain parameters are found to
be excessive, the machine will indicate that the machine requires service. This
warning will remain visible for approximately 10 seconds or until the green button
is pressed.
When the trimming parameters have been tuned, the display will indicate:
