T14SG Software Update Changes
(Version 2.0)
This software update modies features found on the 14SG. If you have questions about these updated directions,
please consult your instruction manual or futaba-rc.com for further details. Refer to the original manual where
applicable but replace the steps indicated below with these instructions.
1.TELEMETRY MONITOR
The telemetry screen is modied.
● TELEMETRY MONITOR set up
① The HOME/EXIT button is pushed from
HOME screen and TELEMETRY MONITOR
is called.
② Move the cursor to the "RECEIVER" or
"SENSOR" (SBS-XXX etc.) and touch the
RTN button.
③ You will use the "Display" function to
choose how many sensors are shown on
your Telemetry monitor.
It pushes from
HOME screen.
To TELEMETRY MONITOR
You can display any items on the telemetry screen
up to 4 items at FASSTest 14CH mode. The benet
of expansion of a character will be obtained by
choosing the display items 1 and 2.
Ex. 1 item is displayed Ex. 2 items are displayed
Ex. 4 items are displayedEx. 3 items are displayed
If the numeric part
(included "+","-",",")
is over the 6 letters, it
becomes the smaller size
automatically. It is same
size as 2 items screen.
In FASSTest12CH mode,
they are only 1 and 2 item
displays.
If a cursor is moved to items (Rx-BATT,
EXT-VOL, TEMP. etc.) and RTN is touched,
the alarm setting screen of the item will be
displayed.
1
1
2
1 3
2 4
[ Display position ]
The Telemetry Monitor is accessed by a quick tap of the
HOME/EXIT
key. Do not press and hold as this
will activate Key Lock.
Key-Lock
Lock or unlock is done either by pressing and holding the
S1
key or by pressing and holding the
HOME/EXIT
key.
