FUTABA T18SZ Quick Start Guide

Magnus Hedlund Page 7
TURBO SPEED
Dual Rate is used for the Turbo speed function (max motor), when used
GLIDER – DUAL RATE
Set flight condition = ‘MOTOR ON’
Status Function Switch
D/R 1 OFF/ON Motor SF (ON in flight condition ‘MOTOR ON’)
(Switch = “SF”, On = down)
GLIDER – AFR
Menu 2: Set Function = Motor
Menu 1: Motor – Dual rate
D/R 1 in flight condition ‘MOTOR ON’: (Set D/R 1 with SF)
Set Rate A = Rate B = 0
Set Offset = +100 equals pulse width = 1940 us.
MOTOR TO ELEVATOR COMPENSATION, when needed
GLIDER – PROGRAM MIXES
Select new mixer, Mode = Mixing
Menu 2:
Set Mixer to ‘ON’
Master: Motor
Slave: Elevator
Menu 1: Point: Position Rate (elevator compensation, usually down.)
-152.5 0
-125 0 = Off
-65 0 = Low
-15 +2 = Mid
+70 +3 = High
+100 +4 = Turbo (High)
+152.5 0
For V-Tail:
Set Slave - Elevator - Link to ‘+’.

FUTABA T18SZ Specifications

General

Channels	18
Frequency	2.4GHz
Telemetry	Yes
Modulation	FASSTest, FASST, S-FHSS, T-FHSS
Display	Color LCD
Model Memory	30
