G-Lab MIDI Guitar Controller - System Exclusive (Sysex) Type Messages

14
Controller’s number Controller’s value Function
0-63 AUX6 switching off
25
64-127 AUX6 switching on
0-63 AUX7 switching off
26
64-127 AUX7 switching on
0-63 AUX8 switching off
27
64-127 AUX8 switching on
0-63 Switch1 switching off
28
64-127 Switch1 switching on
0-63 Switch2 switching off
29
64-127 Switch2 switching on
0-63 Switch3 switching off
30
64-127 Switch3 switching on
0-63 Switch4 switching off
31
64-127 Switch4 switching on
0-63 LOOP1 switching off
52
64-127 LOOP1 switching on
0-63 LOOP2 switching off
53
64-127 LOOP2 switching on
0-63 LOOP3 switching off
54
64-127 LOOP3 switching on
0-63 LOOP4 switching off
55
64-127 LOOP4 switching on
0-63 LOOP5 switching off
56
64-127 LOOP5 switching on
0-63 LOOP6 switching off
57
64-127 LOOP6 switching on
0-63 BUFFER switching off
58
64-127 BUFFER switching on
0-63 LDR S * switching off
59
64-127 LDR S * switching on
0-63 LDR R * switching off
60
64-127 LDR R * switching on
0 Mute ON
7
1-127 Mute OFF
* - for production tests only
System Exclusive (SysEx) type messages
Controller attend two messages SysEx type related to resending and receiving presets and setup memory
content.
F0 00 20 71 14 01 01 F7 – message in this format is interpreted as memory content resending request.
After receiving it the message with memory content is sent out (for more information see System Exclusive
dump memory message specification chapter).
