MIDI implementation chart
G LAB MIDI Guitar Controller MGC-6 rev. 1.01 01.10.2008
Function Transmitted Recognised
Basic Channel
Default 1,2,3,4 1
Changed 1-16 1-16
Mode
Default
Messages X X
Altered
Note Number
XX
True Voice X X
Velocity
Note ON X X
Note OFF X X
After Touch
Keys X X
Channels X X
Pitch Bend
XX
Control Change
0 -127 7, 20-31, 52-61
Prog Change
1-128 1-101
System Excl.
OO
System Common
Song Pos X X
Song Sel X X
Tune X X
System real time
Clock X X
Commands X X
Aux Messages
Local ON/OFF X X
All Notes OFF X X
Active Sense X X
Reset X X
O: YES
X: NO
Errors’ table
The table below shows the list of errors displayed by controller with their description and solving
procedure.
Error1
Memory EEPROM error – contact your dealer
Error2
Disable to send SysEx memory dump message – set MIDI OUT on out mode
Error3
Entered wrong password – enter 106
