Console module »DVI-CON-MC2«
Computer and console modules · 109
Technical data
DVI-CON-MC2
Interfaces to console Video: 2 × DVI-I (DVI single-link or VGA)
Keyboard and mouse signals 2 × PS/2 socket
2 × USB-A
Audio: 2 × 3.5 mm jack plug
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
counterpart
Interfaces: 2 × RJ45 socket
Transmission distance: Max. 140 metres
Video Max. resolutions: 1920 × 1200@60Hz
1280 × 1024@85Hz
Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Colour depth: 24 Bit
Video bandwidth: 25 MHz to 165 MHz
Vertical frequency: 50 Hz to 180 Hz
Horizontal frequency: 30 kHz to 130 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the
monitor to support a maximum number
of monitors. However, the support
cannot be guaranteed for all monitor
models.
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
Main power supply Type: Internal power pack
Connector: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.4 A - 0.2 A
Redundant
power supply
Type: External power pack
Connector: 1 × Mini-DIN 4 socket
Power input: 1.5A @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 270 × 44 × 210 mm
Weight: Approx. 1.53 kg
