Console module »DVI-CON-Video«
170 · Computer and console modules
Console module »DVI-CON-Video«
With DVI-CON-Video console modules, you can connect a DVI monitor or a projector to
a matrix switch of the ControlCenter-Compact or ControlCenter-Digital series.
First connect the monitor or the projector and the audio devices) to the console
module. Then connect the console module to the matrix switch.
The video signal of the accessed computer is displayed at the monitor/projector of
the console module.
Package contents
 1 × DVI-CON-Video console module
 1 × Power cable
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
Required accessories
 1 × Category 5e (or better) twisted pair cable to connect the console module to the
matrix switch or a compatible computer module
ADVICE: You can also connect the console module directly to a compatible computer
module.
